MCS301 - 3ph meter Page 66 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
13.7 Load profile 6 – harmonics and THD values
The load profile 6 should have below characteristic:
• configurable interval, period 3: 1 … 60min
• default interval: 10min
• Configurable number of quantities, up to 15
th
harmonic
• Max. number of channels: 42
• Max. number of days per channel: 31 (10min, 42 channels)
remark: in case the number of channels is less than 42 the size for the other
channels is increased
Harmonic Values Profile (1-0:99.136.0.255)
channel
Quantity OBIS code
1 Last Average Value of 3th harmonic, Voltage, L1 1-0:32.25.3.255
2 Last Average Value of 3th harmonic, Voltage, L2 1-0:52.25.3.255
3 Last Average Value of 3th harmonic, Voltage, L3 1-0:72.25.3.255
5 Last Average Value of 5th harmonic, Voltage, L2 1-0:52.25.5.255
6 Last Average Value of 5th harmonic, Voltage, L3 1-0:72.25.5.255
7 Last Average Value of 7th harmonic, Voltage, L1 1-0:32.25.7.255
8 Last Average Value of 7th harmonic, Voltage, L2 1-0:52.25.7.255
9 Last Average Value of 7th harmonic, Voltage, L3 1-0:72.25.7.255
11 Last Average Value of 9th harmonic, Voltage, L2 1-0:52.25.9.255
12 Last Average Value of 9th harmonic, Voltage, L3 1-0:72.25.9.255
13 Last Average Value of 11th harmonic, Voltage, L1
1-0:32.25.11.255
14 Last Average Value of 11th harmonic, Voltage, L2
1-0:52.25.11.255
15 Last Average Value of 11th harmonic, Voltage, L3
1-0:72.25.11.255
16 Last Average Value of 13th harmonic, Voltage, L1
1-0:32.25.13.255
17 Last Average Value of 13th harmonic, Voltage, L2
1-0:52.25.13.255
18 Last Average Value of 13th harmonic, Voltage, L3
1-0:72.25.13.255
19 Last Average Value of THD, Voltage, L1 1-0:32.25.124.255
20 Last Average Value of THD, Voltage, L2 1-0:52.25.124.255
21 Last Average Value of THD, Voltage, L3 1-0:72.25.124.255
