15 Event Log file
The meter generates a number of Events for additional information concerning the status of
the meter or configuration.
Certain conditions can trigger the event and initiate the logging into the event log. The root
cause for the individual trigger depends on the nature of the events. As long as the root
cause is still active, the event will not be re-triggered. The meter supports different log files:
• 1 - Standard Event Log
• 2 - Fraud Detection Log
• 3 - Disconnector Control Log
• 4 - Power Quality Log
• 5 - Communication Log
• 6 - Power Failure Log
• 7 - Special log with storing index value of 1.8.0
• 8 - M-Bus log
In each event log, different values are stored in case of event. The values of each event log
(Event parameters) and the source COSEM objects are shown in below table.
Event log
Standard Event log
(0-0:99.98.0.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.0.255
Event Parameter (sub events 0-0:96.11.10.255
Fraud detection Event log
(0-0:99.98.1.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.1.255
Communication Event log
(0-0:99.98.5.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.5.255
Disconnect Control Event log
(0-0:99.98.2.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.3.255
Active Threshold value of limiter 0-0:17.0.0.255
Power Quality log
(0-0:99.98.4.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.4.255
Magnitude of Power Quality event 0-0:96.11.11.255
Duration/Number of PQ event 0-0:96.11.11.255
Power Failure Event log
(0-0:99.97.0.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.6.255
Magnitude of Power Quality event 0-0:96.7.19.255
M-Bus Master Control log object 1
(0-0:99.98.1.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.4.255
…
M-Bus Master Control log object 4
(0-0:99.98.1.255)
Clock (time stamp) 0-0:1.0.0.255
Event Code 0-0:96.11.4.255
Table 35: Different Event log and Event parameters
