13.2 Load profile 1 – standard profile
The load profile 1 should have below characteristic:
• configurable interval, period 1: 1 … 60min
• default interval: 15min
• number of channels: 12
• Max. number of days per channel: 92 (15min, 12 channels)
remark: in case the number of channels is less than 12 the size for the remaining
channels increases accordingly
• storage mode per interval
o demand values (x.6.0), x=1 … 10
o energy value per period (ACOR FW 02.02.11)
o index values (x.29.0), x=1 … 10
Selectable energy quantity OBIS code
1 active energy, +A 1-0:1.8.0.255
2 active energy, -A 1-0:2.8.0.255
3 reactive energy, +R 1-0:3.8.0.255
4
reactive en
ergy
,
-
R
1
-
0:4.8.0.255
5 reactive energy, R1 1-0:5.8.0.255
6 reactive energy, R2 1-0:6.8.0.255
7 reactive energy, R3 1-0:7.8.0.255
8 reactive energy, R4 1-0:8.8.0.255
9 apparent energy, +S 1-0:9.8.0.255
10 apparent energy, -S 1-0:10.8.0.255
11 transformer losses, +U*U*h 1-0:83.8.4.255
12 line losses, +I*I*h 1-0:83.8.1.255
13 transformer losses, -U*U*h 1-0:83.8.5.255
14 line losses, -I*I*h 1-0:83.8.2.255
15
line losses, +I*I*h with
normalized R cu =1Ohm 1-0:83.8.20.255
16
transformer losses, +U*U*h with
normalized R FE =1MOhm 1-0:83.8.19.255
17 active energy, /+A/ + /-A/ 1-0:15.8.0.255
18 active energy, /+A/ - /-A/ 1-0:16.8.0.255
Table 28: load profile 1 data – billing data
