17 – Transformer ratio- current denominator changed
18 – Transformer ratio- voltage denominator changed
19- Limiter action activated (Attr. 11, IC 71, changed to any action)
20- Limiter action deactivated (Attr. 11, IC 71, changed to any action)
21- Minimum Time Under Threshold
22- Minimum Time Over Threshold
23- Time Threshold for Under Voltage Detection
24- Time Threshold for Over Voltage Detection
25- Threshold for Under Voltage Detection
26- Threshold for Over Voltage Detection
27- Time Threshold for Missing Voltage
28- Threshold for Missing Voltage
29
-
Time threshold for long power fail
ure
48
Global key(s) changed
One or more global keys changed
,
with sub
-
events
1– Authentication Key for meter change
2 – Encryption Unicast key for meter change
3 – Encryption Broadcast key for meter change
4 – Authentication Key for IHD change
5 – Encryption Unicast key for IHD change
6 – Master Key Change
7- Authentication Key for Local Port
8
-
Encryption Unicast Key for Local Port
51
FW verification failed
T
ransferred firmware verification failed i.e. cannot be activated.
52
Unexpected consumpti
on
C
onsumption is detected at least on
1
ph when the disconnector
was
disconnected
88
Phase sequence reversal
Indicates wrong mains connection. Usually indicates fraud or wrong installation.
89
Missing neutral
N
eutral connection from
s
upplier to meter is
interrupted (but the neutral connec
tion
to the load prevails). Measured
phase voltages may differ from their nominal values
97
Load Mgmt activity calendar
activat.
P
assive Load Management activity calendar has been activated
98
Load Mgmt passive activi
ty calendar
programmed
P
assive Load Management activity calendar has been programmed
108
LPCAP_1 enabled
C
apturing of Load Profile 1 is enabled
109
LPCAP_1 disabled
C
apturing of Load Profile 1 is disabled
117
LPCAP_2 enabled
C
apturing of Load Profile 2
is enabled
118
LPCAP_2 disabled
C
apturing of Load Profile 2 is disabled
203
Manual demand reset
A
manual demand reset
was executed
240
Overvoltage innany phase detected
241
Overvolatge in any phase end
226
Firmware activation failed
F
ailed FW activa
tion
254
Load profile cleared
Any of the profiles cleared.
NOTE: If it appears in Standard Event Log then any of the E-load profiles was cleared. If
event appears in the M-Bus Event log => one of the M-Bus load profiles was cleared
1 – Monthly
2 – LP1 (hourly)
3 – LP2 (daily)
4 - Supervision Average
5 - Supervision Minimum
6 - Supervision Maximum
7 - Supervision Harmonics
8 - LP Mbus1
9 - LP Mbus2
10 – LP Mbus 3
11 – LP Mbus 4
255
Event log cleared
E
vent log was cleared. This is always the first entry in
the effected
event log.
Table 36: Definition of log file 1 - Standard Event Log
