Stress Echo 6-5
In Select Mode, you can select the representative loop (“preferred” loop) for each view. If
you activate Review Mode without first selecting preferred loops, then the system uses the
default loop selection to represent each view (for non-continuous stages). The default
loop selection is the loop acquired immediately prior to the last loop. For example, if four
loops are acquired for every view, then the default loop selection is the third loop.
Loops for views in non-continuous stages are labeled with the view name at acquisition.
Loops for views in continuous stages are labeled with the view name when you select the
“preferred” loop.
To select “preferred” loops:
1. Activate Select Mode by clicking Select Mode icon on the top of the screen.
The system displays the acquired loops for the first view in the protocol (for
non-continuous stages). If the first stage is continuous, then the system displays the
first set of acquired loops for that stage.
2. Select the loop. Use the buttons displayed during Select Mode to designate another
loop or another view for display.
The system outlines the selected loop in blue graphical boarder to indicate selection
and click the selected loop to cancel its “selected state”.
Double click a clip, the clip will be selected, and the system will go for clip
selection of the next view.
Click [Next], [Previous], [First], [Last] to display another loop in the current view.
For a continuous stage, the [Next], [Previous], [First], [Last] buttons display loops
saved for the stage (not the view).
Select Scroll Up or Scroll Down to display another view.
For a continuous stage, click the Scroll Up and Scroll Down buttons to
display the preferred loop for the view. If no loop is designated as preferred for
the selected view, then these buttons have no effect.
3. Select the stage and view to display all loops for the view and then continue
designating the “preferred” loop for each displayed view until all views are completed.
Description of select mode pertinent soft menu keys:
Selection Description
1.Clip/2.Clip/3.Clip/4.Clip
For selecting views in the selected stage.
Next Next four Clips.
Previous Previous four Clips.
First Go to “first” Clips.
Last Go to “last” Clips.
Text “On”/“Off” Function that turns on screen graphic text “On”/“Off”. The
function is the same as Labels on/off icon on the top of the
screen.
Information includes: name of level, name of view, heart rate,
time stamp acquisition, timers, frame slider, loop ID, clip
control. For the cine without distributed view, name of level,
name of view are displayed in “---”.
Apply edit all Clip edit applied to all clips taken.
