15-4 Setup
Region Items Description
Confirmation
when exam ends
To set if the system pops up prompts “Do you want
to end the current/active exam” when end an exam.
Patient
Management
Save image
without patient
info
For an anonymous patient exam, you can save
images without entering any patient information. If
you check “Auto generated ID” ([Setup]→[System
Preset]→ [General]), the system will save the
images using the auto generated ID.
Auto generated ID
Check the item to generate an ID automatically
when begins an exam for a new patient.
Send/print Image
after print after
End Exam
Select if to automatically archive the exam data.
Storage
Image Size
To set the size for a stored image :
640*480.
800*600.
1024*768.
Clip length/ Time
(s)
To set the cine length when no ECG loop is
included. Value: 1~60s.
Clip length/
Beat(heart cycle)
To set the number of ECG loops in a saved cine.
Value: 1~16.
JPG Compress To set the compression ratio: H, M, L.
File system type
To set the file system type when record data to a
CD: UDF, ISO.
Prospective Cine
Length
To set the cine length for prospective live capture.
Value: 1-480s, or 1-120 cycles.
Retrospective
Cine Length
To set the cine length for retrospective live capture.
Value: 1-120s, or 1-120 cycles.
Image/ clip
storage
While storing
image to hard disk
Select the accompanying image sending
destination: local default printer; DICOM Storage;
DICOM Printer.
While Storing Clip
to hard disk
Select the accompanying clip sending destination:
DICOM Storage.
Screen Saver
Enable Screen
Saver
To enable screen saver function, and select the
waiting time until screen saver.
Enable Standby
To enable the standby function, you can select the
waiting time for entering standby after screen saver.
Operation Log
Enable logging To set if to enable logging the operation log.
Auto Upload To set if to automatically upload the operation log.
15.1.3 Image Preset
Open the Image Preset page via “[Setup] → [System Preset] → [Image Preset]”.
