Mindray M7T - Basic Screen and Operation

3-10 System Preparation
3.9 Basic Screen and Operation
3.9.1 Basic Screen
The following diagram maps out the different areas in the screen:
Logo
Hospital Name
Exam
Time
Acoustic
Power
MI/TI
Accession#
Freeze
icon
Patient Information Probe
Exam
Mode
Operator
ECG
icon
Parameter and
Menu Area
Image area
Thumbnail Area of
Images Stored
Image-in-image
Thumbnail
Cine Review
Body Mark Area
Help information area Cursor area
Soft Menu Area System status icon
 Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, patient information, probe model, current exam
mode, ECG icon (if ECG module is connected), and accession #, etc.
To preset whether gender, age or operator is displayed: Enter "[Setup]→[System
Preset]→[General Preset]" and check "Gender", "Age" or "Operator" in the [Patient
Info] box in the upper left corner of the screen.
 Logo
Manufacture logo, displayed in the upper left corner of the screen.
 Hospital name
Display the hospital name. Hospital name can be set via "[Setup] → [System
Preset] → [Region]".
 Exam time
Displays the exam time, including date and time. Exam time can be set via
"[Setup]→[System Preset]→[Region]". Exam time will be frozen with the frozen
image.
