System Preparation 3-15
3.9.2 Basic Operations of Screens
A screen consists of title, page tabs, contents and buttons, as shown in the following
figure:
Composition Description
Title Bar
The title bar is used to give a description for the content and
function of the screen.
Page Tab
For some screens, contents are distributed across several
pages. Click the tab by pressing <Set> key to open/close the
available pages.
Contents
 Radio button: click to select the item.
 Check box: click to check or uncheck the item.
 Entry box: enter characters manually via the keyboard.
Position the cursor into the box, and then enter the letters
or characters.
 Drop-down list box: click “▼” to show the list and select
an item.
[OK] and [Cancel]
When the operation of a screen is complete, press the [OK]
or [Cancel] button to save or cancel the operation, and close
the screen.
 To reposition a dialogue box:
1. Roll the trackball to move the cursor onto the title bar of the dialogue box. At this time
the cursor becomes a ; press <Set>.
2. Roll the trackball and reposition the rectangular graphic to the new desired location.
3. Press the <Set> key, and the dialogue box is moved to the desired position.
Title
Tab
Content
Control
button
