9.1.Standard RS-485 interface
210
External equipment
9
(5) Stop bit setting
Sets the stop bit of the standard RS-485 interface.
1) Set a stop bit
1. Select a stop bit.
6HOHFWLRQVELWELW
,QLWLDOYDOXHELW
2. Tap [OK].
The stop bit will be set, and [RS485 1/2] will be
displayed.
2) Check the setting that you set
1. Check the stop bit setting.
The setting is completed if the item set by the step
1) above appears under [STOP BITS].
(6) Terminator setting
Sets the terminator of the standard RS-485 interface.
1) Set a terminator
1. Select a terminator.
6HOHFWLRQV&5&5/)
,QLWLDOYDOXH&5/)
2. Tap [OK].
The terminator will be set, and [RS485 1/2] will be
displayed.
2) Check the setting that you set
1. Check the terminator setting.
The setting is completed if the item set by the step
1) above appears under [TERMINATOR].
