5. Accessing the internal parts
MiR250 Hook User Guide (en) 01/2023 - v.1.2 ©Copyright 2021-2023: Mobile Industrial Robots A/S. 51
2 Loosen the bottom corners one at the time by pulling out each corner.
3 Loosen the top corners one at the time by pulling each corner down, and then out.
4 Pull off the cover.
