Mitel 430 - Routing elements

Installation
103
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Notes:
– This cable cannot be used to connect PRI and Ethernet interfaces (see also "Connection of
PRI primary rate interface", page 110 and "Connection of Ethernet interfaces", page 145).
– It is not possible to connect an ODAB door intercom interface with only one cable (see also
"Connection of a door intercom (TFE)", page 138).
Tip
Use standard commercial connecting cables not just for the PRI and Ethernet interfaces but
also for connecting the BRI-T interfaces.
Tab. 37 Schematic diagram of prefabricated system cable 12 × RJ45
Stranded
element
Core colour
Cable desig-
nation
RJ45 Signal
Pin Connection four-wire Two-wire connection
1white 1 4 f a
blue 5 e b
turquoise 6 d –
violet 3 c –
2white 2 4 f a
orange 5 e b
turquoise 6 d –
violet 3 c –
3white 3 4 – a
green 5 – b
turquoise 4 4 – a
violet 5 – b
4white 5 4 – a
brown 5 – b
turquoise 6. 4 – a
violet 5 – b
5white 7 4 – a
grey 5 – b
turquoise 8 4 – a
violet 5 – b
6 red 9. 4 – a
blue 5 – b
turquoise 10 4 – a
violet 5 – b
7red 11 4 – a
orange 5 – b
turquoise 12 4 – a
violet 5 – b
