Installation
146
Mitel 415/430 as of R4.1
syd-0580/1.2 – R4.1 – 08.2016
Note:
DHCP is deactivated only temporarily and is reactivated after a subsequent restart.
Cable types
The Ethernet switch on the communications server features Auto MDI/MDIX. With the
automatic detection straight or crossover LAN cables can be used for all connection
types.
Configuration
The Ethernet interfaces routed to the front panel can be configured individually in the
IP addressing ( =9g) view. In addition to Auto modes, manual settings are also possi-
ble for Speed and MDI type.
Status LED
The status of the Ethernet interface LAN1 is indicated on the LED display panel (see
"
LED display", page 200).
Cable Requirements
Use commercial Cat. 5 cable, or choose a cable type with the following characteristics:
Tab. 75 Requirements for an Ethernet cable
See also:
For more information about the Ethernet interface on the application card, see the CPU2-S
application card installation manual.
Core pairs
×
cores 2
×
2 (short distances also 1
×
4)
Stranded yes
Wire diameter, core 0.4...0.6 mm
Screening yes
Category Cat. 5 minimum
