FX3U Series Programmable Controllers
User's Manual - Hardware Edition
Standards
Type : Programmable Controller (Open Type Equipment)
Models : MELSEC FX3U series manufactured
from May 1st, 2005 FX3U-MR/ES
Where  indicates:16,32,48,64,80
FX3U-4HSX-ADP FX3U-2HSY-ADP
FX3U-FLROM-16 FX3U-FLROM-64L
FX3U-7DM
from June 1st, 2005 FX3U-232ADP FX3U-485ADP
FX3U-4AD-ADP FX3U-4DA-ADP FX3U-4AD-PT-ADP FX3U-4AD-TC-ADP
FX3U-232-BD FX3U-422-BD FX3U-485-BD FX3U-CNV-BD
FX3U-USB-BD
FX3U-FLROM-64
from November 1st, 2005 FX3U-MT/ES FX3U-MT/ESS
Where  indicates:16,32,48,64,80
from February 1st, 2006 FX3U-128MR/ES FX3U-128MT/ES FX3U-128MT/ESS
FX3U-MR/DS FX3U-MT/DS FX3U-MT/DSS
Where  indicates:16,32,48,64,80
from April 1st, 2007 FX
3U-232ADP-MB FX3U-485ADP-MB
from December 1st, 2007 FX3U-4AD-PTW-ADP FX3U-4AD-PNK-ADP
from June 1st, 2009 FX3U-3A-ADP FX3U-CF-ADP
from August 1st, 2010 FX3U-8AV-BD
from September 1st, 2010 FX3U-MS/ES FX3U-MR/UA1
Where  indicates:32,64
from May 1st, 2011 FX
3U-FLROM-1M
Standard Remark
EN61131-2:2007 Programmable controllers
- Equipment requirements and tests
Compliance with all relevant aspects of the standard.
EMI
• Radiated Emission
• Conducted Emission
EMS
• Radiated electromagnetic field
• Fast transient burst
• Electrostatic discharge
• High-energy surge
• Voltage drops and interruptions
• Conducted RF
• Power frequency magnetic field
