FX3U Series Programmable Controllers
User's Manual - Hardware Edition
Standards
Models : MELSEC FX2N series manufactured
For the products above, PLCs manufactured
before March 31st, 2002 are compliant with EN50081-2 (EN61000-6-4) and EN50082-2
from April 1st, 2002 to April 30th, 2006 are compliant with EN50081-2 (EN61000-6-4) and EN61131-2:1994
+A11:1996+A12:2000
after May 1st, 2006 are compliant with EN61131-2:2007
from July 1st, 1997 FX2N-ER-ES/UL FX2N-ET-ESS/UL
Where  indicates:32,48
FX
2N-16EX-ES/UL FX2N-16EYR-ES/UL FX2N-16EYT-ESS/UL
from April 1st, 1998 FX2N-48ER-DS FX2N-48ET-DSS
from August 1st, 1998 FX2N-48ER-UA1/UL
from August 1st, 2005 FX2N-8ER-ES/UL FX2N-8EX-ES/UL FX2N-8EYR-ES/UL
FX2N-8EYT-ESS/UL
from September 1st, 2010 FX2N-8EYR-S-ES/UL
Standard Remark
EN61000-6-4:2007 - Generic emission standard
Industrial environment
EN50081-2:1993 Electromagnetic compatibility
Compliance with all relevant aspects of the standard.
• Emission-Enclosure port
• Emission-Low voltage AC mains port
• Emission-Telecommunications/network port
EN50082-2:1995 Electromagnetic compatibility
- Generic immunity standard
Industrial environment
Compliance with all relevant aspects of the standard.
• RF immunity
• Fast Transients
• ESD
• Conducted
• Power magnetic fields
EN61131-2:1994 Programmable controllers
/A11:1996 - Equipment requirements and tests
/A12:2000
Compliance with all relevant aspects of the standard.
• Radiated electromagnetic field
• Fast transient burst
• Electrostatic discharge
• Damped oscillatory wave
EN61131-2:2007 Programmable controllers
- Equipment requirements and tests
Compliance with all relevant aspects of the standard.
EMI
• Radiated Emission
• Conducted Emission
EMS
• Radiated electromagnetic field
• Fast transient burst
• Electrostatic discharge
• High-energy surge
• Voltage drops and interruptions
• Conducted RF
• Power frequency magnetic field
