To specify the desired value using an analog signal, you need to create a
signal at the Desired value setting release input. If this is not done, the de-
vice uses the set desired value 1.
Setting desired value 1
To set the desired value, proceed as follows:
1. Go to Settings > Parameters > Control > Desired value.
2. Enter desired value.
3. Press the Accept button to save the modified parameter.
Setting max. desired value setting
With this parameter, you can set the desired value that corresponds to the
maximum level of the analog signal level (e.g. 20 mA for 4...20 mA signal).
1. Go to Settings > Parameters > Control > Setting max. desired value.
2. Enter desired value.
3. Press the Accept button to save the modified parameter.
Setting min. desired value setting
With this parameter, you can set the desired value that corresponds to the
minimum level of the analog signal (e.g. 4 mA for 4...20 mA signal).
1. Go to Settings > Parameters > Control > Setting min. desired value.
2. Enter desired value.
3. Press the Accept button to save the modified parameter.
7.3.1.5 Step-by-step setting of the desired value
For the step-by-step setting of the desired value, you can increase or de-
crease the desired value for the automatic voltage regulation by an ad-
justable step width using digital inputs or control system commands.
For each "Increase desired value" or "Decrease desired value" command,
the active desired value is increased or decreased by the set step width. It is
not possible to set desired values outside of the permitted setting range
(49...140 V).
The device only processes commands via digital inputs or the control sys-
tem when it is in the Remote mode. You must also set the Remote behavior
[►Section 7.2.5, Page 96] parameter accordingly.
In order to configure the step-by-step setting of the desired value, you can
set the parameters as described below.
