12 Technical data
Maschinenfabrik Reinhausen GmbH 2019388 5163667/06 ENETOS
®
IM
Interfaces
Interface Pin Description
L1
NC
L2
NC
L3
N
L1 Voltage input for phase L1
NC Not used
L2 Voltage input for phase L2
NC Not used
L3 Voltage input for phase L3
N Voltage input for neutral conductor
Table129: Voltage measurement
Interface Pin Description
k1
l1
k2
l2
k3
l3
k1, l1,
k2, l2,
k3, l3
No function
Table130: Current measurement
Interface Pin Description
1A, 1B,
1C, 2A,
2B, 2C
No function
Table131: Relay
12.5 Digital inputs and outputs
DIO 28-15 DIO 42-20 DIO 42-20 HL
Inputs (plug-based
electrical isolation)
Quantity 28 42
Logical 0 0...10 V AC (RMS)
0...10 V DC
0...40 V AC (RMS)
0...40 V DC
Logical 1 18...260 V AC (RMS)
18...260 V DC
170...260 V AC (RMS)
170...260 V DC
Input current Typ. 1.3 mA (regardless of U)
Simultaneity factor at 70 °C and U ≥ 230 V: max. 50 %
