13.1 Check list for commissioning
Observe the following check list to perform commissioning:
No. Description Complete
1 Cap rail corresponds to standard IEC 60715 type TH 35-7.5
or TH 35-15 and is mounted horizontally.
2 The distance of the screws for fastening the cap rail is a max-
imum of 10cm.
3 The assemblies have been mounted and engaged correctly
on the cap rail. The assemblies are securely in place on the
cap rail.
4 The device has been installed correctly and the minimum dis-
tances [►Section 5.3, Page 51] observed.
5 The supply line is dimensioned in accordance with the perfor-
mance data on the nameplate.
6 The supply line is fused with a miniature circuit breaker of
type C6A or B6A.
7 The 24V supply cables are connected using a terminal strip
that is located near the power supply.
8 The cable cross-section of the 24V voltage supply is 1.5mm²
9 The 24V supply cables are not longer than 2.5m
10 The 24V supply is connected exclusively to the assemblies
of this device in accordance with the connection diagram.
11 Voltage transformers and current transformers are designed
for connection to the inputs for voltage measurement and cur-
rent measurement (see technical data [►Section 12, Page
385]).
12 The DIO assembly is connected correctly to the CPU assem-
bly using the provided CAN bus cable. For CAN bus cables
longer than 2m, the plug with the CPU label must be plugged
into the CPU assembly.
13 The shielding of the analog signals (AIO assembly) is applied
on both sides.
14 The communication cables correspond to the cable recom-
mendation
15 The dielectric test has been performed and passed [►Sec-
tion 6.1.2, Page 87].
16 The ground test has been performed and passed [►Section
6.1.1, Page 85].
17 The values measured by the device and the status of the digi-
tal inputs are plausible.
18 The configured limit values are plausible.
Table163: Check list
