12 Technical data
Maschinenfabrik Reinhausen GmbH 2019 3935163667/06 EN ETOS
®
IM
Optional accessories
CAN bus Terminating resistor
▪ D-SUB plug connector (9-pole)
▪ R = 120Ω
Connector with terminal strip for directly connecting CAN
lines
Media converter for
COM2 interface (only
RS232)
Adapter from D-SUB (9-pole) to fiber-optic cable:
▪ ACF660/ST: F-ST, 660nm, range max. 60m at
40kBaud
▪ ACF660/SMA: F-SMA, 660nm, range max. 60m at
40kBaud
▪ ACF850/ST: F-ST, 850nm, range max. 1000m at
40kBaud
▪ ACF850/SMA: F-SMA, 850nm, range max. 1000m at
40kBaud
Table142: Optional accessories
12.8 System networking
MC 2-2
Description Media converter
Interfaces 2x RJ45
2x duplex LC (SFP)
RJ45 Max. 100m (per section)
10/100 Mbit/s
Cable impedance 100Ω
Fiber-optic cable Max. 2,000 m
100 Mbit/s
Light-emitting diode: class 1
Wave length: 1310nm
Max. optical output power: <1 mW (in accordance
with IEC 60825-1:2014)
Table143: Technical data for the MC 2-2 assembly
SW 3-3
Description Managed Fast Ethernet Switch in accordance with
IEEE 802.3, store-and-forward-switching
Interfaces 2x RJ45
2x duplex LC (SFP)
Redundancy protocols PRP
1
, RSTP
Time synchronization PTPv2 (IEEE 1588-2008)
