4.4.11 Bushing adapter and bushing coupling unit
The bushing adapter is used to pick up the measured voltage at the bushing
test tap. The downstream bushing coupling unit is used to adjust the mea-
sured voltage. Both components are tuned to the bushings to be monitored
in accordance with your order. They may be used only for those bushings.
The following components are used:
▪ Bushing adapter (A001...A008)
▪ C002: Bushing coupling unit
Type Bushing types
A001 Micafil RTKF
Micafil RTKG
A002 HSP SETFt 1550/420-1800
HSP SETFt 600/123-2000
A003 ABB GOB 1050-750-1100-0.6-B
ABB GSA 123-OA/1600/0.5
ABB GSA 52-OA/2000/0.5
A004 Trench COT 750-800
A005 HSP SETFt 750-170-4000
HSP SETFt 1200/245-1250
HSP SETFt 1425-420-1600
HSP SESTFt 1050-245-B E6 B
HSP SESTFt 1425-420-B E6 B-1600A
HSP EKTG 72.5-800 kV
A006 PCORE CSA standard POC ser. 2
ABB GOE, GSB (245...550kV)
A007 PCORE B-81515-57-70
A008 Passoni Villa PNO, POBO, PCTO, PAO < 110 kV
Table8: Bushing adapter
