7.30 Linking signals and events
The device allows you to link digital inputs (GPI) and control system com-
mands (SCADA) with device functions, digital outputs (GPO), and control
system messages.
The digital inputs available are each permanently linked to a Generic digital
input event message and the control system commands available are each
permanently linked to aGeneric SCADA command event message for this
purpose.
Input/command Event message
Digital input 1
1)
Generic digital input 1
Digital input 2
1)
Generic digital input 2
... ...
Digital input 42
1)
Generic digital input 42
Generic SCADA command 1 Generic SCADA command 1
Generic SCADA command 2 Generic SCADA command 2
... ...
Generic SCADA command 10 Generic SCADA command 10
Table93: Linking of digital inputs and control system commands with event messages
1)
The number of available digital inputs depends on the order-specific device
configuration.
You can link the event messages with device functions, digital outputs, and
control system messages. You can also link all other event messages (e.g.
undervoltage U<) with digital outputs and control system messages. Corre-
sponding parameters, for which you need to enter the relevant event num-
ber, are provided for this purpose.
7.30.1 Linking functions
You can link the Generic digital input or Generic SCADA command events
with device functions. This allows you to remotely control the device using
digital inputs or commands via the control system (SCADA). Depending on
your device configuration, the following parameters are available for this pur-
pose:
Parameter Description
Master parallel operation method If the assigned event is active, the device
activates the master parallel operation
method.
Follower parallel operation method If the assigned event is active, the device
activates the follower parallel operation
method.
Automatic tap synchronization parallel
operation method
If the assigned event is active, the device
activates the automatic tap synchroniza-
tion parallel operation method.
