MR ETOS IM - Uninstalling the QS3.241 Assembly

10 Uninstallation
Maschinenfabrik Reinhausen GmbH 2019 3815163667/06 EN ETOS
®
IM
10.6 Uninstalling the QS3.241 assembly
1. Open the lever and remove the neutral conductor (N), phase conductor
(L) and the protective conductor .
Figure256: Removing the neutral conductor, phase conductor and protective conductor
2. Open the lever and remove the wiring .
