To set the switching pulse pause, proceed as follows:
1. Go to Settings > Parameters > Motor control > Switching pulse
pause.
2. Enter switching pulse pause.
3. Press the Accept button to save the modified parameter.
7.6.2 Setting motor runtime monitoring
The motor-drive unit's runtime can be monitored by the device. This function
is used to identify motor-drive unit malfunctions during the tap-change oper-
ation and to trigger any actions needed.
Behavior The motor-drive unit issues the Motor-drive unit running signal during the
tap-change operation. This signal is present until the tap-change operation is
complete. The device compares the duration of this signal with the set motor
runtime. If the set motor runtime is exceeded, the device triggers the follow-
ing actions:
1. Motor runtime exceeded event.
2. Pulse signal via Trigger motor protective switch output relay
Note that motor-drive units with cycle settings or motor-drive units without
stepped switching behavior will run for longer under certain circumstances.
Set a longer motor runtime for such units.
The following parameters are available to configure the motor runtime moni-
toring:
▪ Motor runtime
▪ Motor runtime monitoring
Motor runtime
You can use this parameter to set the motor runtime. Proceed as follows:
1. Go to Settings > Parameters > Motor control > Motor runtime moni-
toring.
2. Enter motor runtime.
3. Press the Accept button to save the modified parameter.
Motor runtime monitoring
You can use this parameter to activate or deactivate motor runtime monitor-
ing. Proceed as follows:
1. Go to Settings > Parameters > Motor control > Motor runtime moni-
toring.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.
