12 Technical data
Maschinenfabrik Reinhausen GmbH 2019398 5163667/06 ENETOS
®
IM
Bushing adapter A008
Bushing type Passoni Villa
PNO, POBO, PCTO, PAO
< 110 kV
Dimensions Ø45 x 70mm
Input Test tap Ø8mm (female)
Thread Outer, 1⅛" – 12UNF
Gasket O-ring, 25 x 2.5 NBR 70
Output N female connector
Permitted ambient temperature during opera-
tion
-40 °C...+90 °C
Degree of protection (IEC 60529) IP66
Weight approx. 150g
Table155: Technical data for the bushing adapter A008
12.10.2 Bushing coupling unit
Bushing coupling unit C002
Dimensions (width x height x depth) 117 x 100 x 60mm
Input N female connector
Output Voltage measurement (U) TNC female connector
Partial discharge measurement (PD); is
not used
Capacitance In accordance with order:
0.33...4.5µF (±5%)
Output voltage Typ. (RMS): 75VAC
Max. (RMS): 100VAC
Permitted ambient temperature during operation -40...+80°C
Degree of protection (IEC 60529) IP66
Weight approx. 1.2kg
Table156: Technical data for the bushing coupling unit
