Reference time
You can use this parameter to set which time is to be transmitted by the con-
trol system. The device uses this information for time synchronization
[►Section 7.25, Page 292]. You can select the following options:
Option Description
Local The control system transmits the local time.
UTC The control system transmits the time as UTC. The de-
vice calculates the local time from UTC and the set time
zone [►Section 7.25.3, Page 294].
Table76: Reference time
To set the reference time, proceed as follows:
1. Go to Settings > Parameters > DNP3 > Reference time.
2. Select the desired option.
3. Press the Accept button to save the modified parameter.
7.23.7 Configuring GOOSE (optional)
You can use the optional GOOSE function to send GOOSE messages
(GOOSE publisher) or receive GOOSE messages (GOOSE subscriber) via
the IEC 61850 control system protocol with the device.
The configuration of GOOSE is described in the following sections.
7.23.7.1 Importing CID/SCD file
Note the following definitions for importing a CID file or SCD file.
Only the following elements may differ between the imported IED and the
exported IED from the TEMPLATE.icd.
▪ DataSet elements can be created in each LN
▪ ReportControl elements can be created in the LN containing the associ-
ated DataSet
▪ IP address (if this is not present, the preset one is used)
▪ Subnet mask (if this is not present, the preset one is used)
▪ Gateway IP address (if this is not present, the preset one is used)
▪ Name of IED (IED name)
▪ Name of AccessPoint (AccessPoint attribute name)
▪ Name of logical device (LDevice attribute inst)
OSI-PSEL, OSI-SSEL, and OSI-TSEL cannot be adjusted.
The SCD file may contain no more than 45 IEDs. It may take several min-
utes to import a complete SCD file. The SCD file should only contain the
IEDs needed.
