2. Insert and fasten the plug into the respective "24 V DC" slot.
Figure52: Fastening the 24VDC plug
5.6.8 Wiring the UI 1/UI 3/UI 5 assembly
To wire the UI 1/UI 3/UI 5 assembly, proceed as follows:
1. Guide the leads into the corresponding plug terminals and fasten them us-
ing a screwdriver.
Figure53: Example: Plug for voltage measurement
