7.13 Cooling system control (optional)
You can use the cooling system control function package to control and/or
monitor up to 6 cooling stages depending on device configuration. You can
set parameters for the following cooling stages:
Cooling stage Meaning
S0 Operation without cooling stage
S1 Operation with cooling stage 1
S2 Operation with cooling stage 2
S3 Operation with cooling stage 3
S4 Operation with cooling stage 4
S5 Operation with cooling stage 5
S6 Operation with cooling stage 6
7.13.1 Configuring cooling stages
To control the cooling system you have to set the following parameters for
every cooling stage:
▪ Operating duration
▪ Number of starts
▪ Activate cooling stage
▪ Switch on input variable
▪ Switch off input variable
▪ Switching point
▪ Hysteresis
▪ Switch-on delay
▪ Alternating mode
▪ Periodic mode
▪ Active if error
