7 Operation
Maschinenfabrik Reinhausen GmbH 2019110 5163667/06 ENETOS
®
IM
Desired
value
BCD input
100 80 40 20 10 8 4 2 1
111 V 1 0 0 0 1 0 0 0 1
112 V 1 0 0 0 1 0 0 1 0
113 V 1 0 0 0 1 0 0 1 1
114 V 1 0 0 0 1 0 1 0 0
115 V 1 0 0 0 1 0 1 0 1
116 V 1 0 0 0 1 0 1 1 0
117 V 1 0 0 0 1 0 1 1 1
118 V 1 0 0 0 1 1 0 0 0
119 V 1 0 0 0 1 1 0 0 1
120 V 1 0 0 1 0 0 0 0 0
121 V 1 0 0 1 0 0 0 0 1
122 V 1 0 0 1 0 0 0 1 0
123 V 1 0 0 1 0 0 0 1 1
124 V 1 0 0 1 0 0 1 0 0
125 V 1 0 0 1 0 0 1 0 1
126 V 1 0 0 1 0 0 1 1 0
127 V 1 0 0 1 0 0 1 1 1
128 V 1 0 0 1 0 1 0 0 0
129 V 1 0 0 1 0 1 0 0 1
130 V 1 0 0 1 1 0 0 0 0
131 V 1 0 0 1 1 0 0 0 1
132 V 1 0 0 1 1 0 0 1 0
133 V 1 0 0 1 1 0 0 1 1
134 V 1 0 0 1 1 0 1 0 0
135 V 1 0 0 1 1 0 1 0 1
136 V 1 0 0 1 1 0 1 1 0
137 V 1 0 0 1 1 0 1 1 1
138 V 1 0 0 1 1 1 0 0 0
139 V 1 0 0 1 1 1 0 0 1
140 V 1 0 1 0 0 0 0 0 0
Table18: BCD-coded desired value
Setting desired value 1
To set the desired value, proceed as follows:
1. Go to Settings > Parameters > Control > Desired value.
2. Enter desired value.
