3 IT security
Maschinenfabrik Reinhausen GmbH 201922 5163667/06 ENETOS
®
IM
Figure1: ETH1.2 interface on the OT1205 assembly
Interface Protocol Port Description
ETH1.2 TCP 21 FTP service access
1)
ETH1.2 TCP 80 Web visualization
1)
ETH1.2 TCP 443 SSL-protected web visualization
ETH1.2 TCP 990 SSL-protected FTP service access
ETH1.2 TCP 8080 Web visualization (alternative port)
1)
ETH1.2 TCP 8081 SSL-protected web visualization (alternative
port)
Table4: Interfaces and open ports of the OT1205 assembly
1)
Port is closed if you activate the device's SSL encryption.
Figure2: Interfaces of the CPU assembly
