7 Operation
Maschinenfabrik Reinhausen GmbH 2019274 5163667/06 ENETOS
®
IM
Be sure to enter a valid network mask that is not 0.0.0.0, otherwise it will not
be possible to connect to the device.
To set the subnet mask, proceed as follows:
1. Go to Settings > Parameters > DNP3 > Subnet mask.
2. Enter the subnet mask.
3. Press the Accept button to save the modified parameter
Gateway address (only with TCP transmission type
You can use this parameter to set the gateway's IP address.
If you set the value to 0.0.0.0, no gateway is used.
To set the gateway address, proceed as follows:
1. Go to Settings > Parameters > DNP3 > Gateway address.
2. Enter the gateway address.
3. Press the Accept button to save the modified parameter
TCP port (only with TCP transmission type)
You can use this parameter to set the TCP port.
To set the TCP port, proceed as follows:
1. Go to Settings > Parameters > DNP3 > TCP port.
2. Enter the TCP port.
3. Press the Accept button to save the modified parameter
Serial interface (only with serial transmission type)
You can use this parameter to select the serial interface for data transmis-
sion. You can select the following options:
▪ RS232
▪ RS485
To select the serial interface, proceed as follows:
1. Go to Settings > Parameters > DNP3 > Serial interface.
2. Select serial interface.
3. Press the Accept button to save the modified parameter.
