MR ETOS IM - Page 369

9 Messages
Maschinenfabrik Reinhausen GmbH 2019 3695163667/06 EN ETOS
®
IM
No. Name Description Remedy Q
1
1309 F2-C: Standardization mea-
surement system unstable
Standardization of field 2 not per-
formed due to an unstable mea-
surement system.
Check the reference system, the
bushing coupling units, the wiring,
and the transformer operating
conditions in field 2.
A
1310 F2-tanδ: Dissipation factor
monitoring deactivated
Dissipation factor monitoring has
been deactivated for field 2.
Activate dissipation factor moni-
toring of the bushings for field 2.
-
1311 F2-tanδ: Dissipation factor
monitoring inactive
Dissipation factor monitoring is
not currently being performed in
field 2.
Dissipation factor monitoring will
be performed in field 2 after a de-
lay time has elapsed.
-
1312 F2-tanδ: Standardization not
performed
Dissipation factor monitoring not
performed in field 2 due to stan-
dardization not being performed.
Perform standardization of the
dissipation factor monitoring for
field 2.
-
1313 F2-tanδ: Phase angle devia-
tion too high
Dissipation factor monitoring not
performed in field 2 due to the
phase angle deviation for the 3
phases of the reference system
being too high.
Check the reference system and
the wiring in field 2.
-
1314 F2-tanδ: Measured voltage
too low
Dissipation factor monitoring not
performed in field 2 due to the
voltage on the bushing coupling
units being too low.
Check the bushing coupling units,
the wiring, the bushings and the
transformer operating conditions
in field 2.
-
1315 F2-tanδ: Limit value Δtanδ >
phase L1
The limit value for the deviation of
the dissipation factor has been
exceeded for the bushing of
phase L1 in field 2.
Check the curve for the change in
dissipation factor in field 2. Check
the dissipation factor of the bush-
ing using an external measuring
device.
-
1316 F2-tanδ: Limit value Δtanδ >
phase L2
The limit value for the deviation of
the dissipation factor has been
exceeded for the bushing of
phase L2 in field 2.
Check the curve for the change in
dissipation factor in field 2. Check
the dissipation factor of the bush-
ing using an external measuring
device.
-
1317 F2-tanδ: Limit value Δtanδ >
phase L3
The limit value for the deviation of
the dissipation factor has been
exceeded for the bushing of
phase L3 in field 2.
Check the curve for the change in
dissipation factor in field 2. Check
the dissipation factor of the bush-
ing using an external measuring
device.
-
1318 F2-tanδ: Limit value Δtanδ >
multiple phases
The limit value for the deviation of
the dissipation factor has been
exceeded for the bushings of mul-
tiple phases in field 2.
Check the reference system and
the curve for the changes in dissi-
pation factor in field 2. Check the
dissipation factor of the bushings
using an external measuring de-
vice.
-
Table121: Event messages
1
A = Event can be acknowledged
