12 Technical data
Maschinenfabrik Reinhausen GmbH 2019396 5163667/06 ENETOS
®
IM
Bushing adapter A003
Bushing type ABB
GOB 1050-750-1100-0.6-B
GSA 123-OA/1600/0.5
GSA 52-OA/2000/0.5
Dimensions Ø40 x 82mm
Input Test tap Ø4mm (female)
Thread Outer, M30x2
Gasket O-ring, 32 x 2 NBR 70
Output N female connector
Permitted ambient temperature during opera-
tion
-40 °C...+90 °C
Degree of protection (IEC 60529) IP66
Weight approx. 190g
Table150: Technical data for the bushing adapter A003
Bushing adapter A004
Bushing type Trench
COT 750-800
Dimensions Ø25 x 61mm
Input Test tap Ø4mm (female)
Thread Outer, M16x1.5
Gasket O-ring, 14 x 2 NBR 70
Output N female connector
Permitted ambient temperature during opera-
tion
-40 °C...+90 °C
Degree of protection (IEC 60529) IP66
Weight approx. 60g
Table151: Technical data for the bushing adapter A004
Bushing adapter A005
Bushing type HSP
SETFt 750-170-4000
SETFt 1200/245-1250
SETFt 1425-420-1600
SESTFt 1050-245-B E6 B
SESTFt 1425-420-B E6 B-1600A
EKTG 72.5-800 kV
Dimensions Ø45 x 71mm
Input Test tap Ø4mm (female)
Thread Outer, M24x1.5
Gasket O-ring, 22 x 2.5 NBR 70
