5 Mounting
Maschinenfabrik Reinhausen GmbH 2019 735163667/06 EN ETOS
®
IM
2. Insert and screw the plug into the respective slot in accordance with the
supplied connection diagram.
Figure61: Fastening the plug (analog inputs/outputs)
Voltage supply
Connect the AIO 2/AIO 4/AIO 8 assembly to the voltage supply of the volt-
age supply unit:
1. Guide the leads into the plug terminal and fasten them using a screw-
driver.
Figure62: Inserting the leads
