PTS 400.3 PLUS Operation Manual_R02 Page 43/306
The display can be switched off for protection and energy saving after a selected time in-
terval. This can be useful during long duration power quality recording sessions. The dis-
play is switched on again by any key operation and the interval is restarted.
Use the up/down cursor keys to select between: 1, 5, 15, 30,
60 min or OFF (cyclical mode)
The screen saver function is switched off. The display is per-
manently on.
The Tool-Tip timeout can be selected from 0.5s to 10s. The Tool-
Tip text will be displayed in the status line for the defined time.
The Tool-Tip description will not appear in the status line.
The Tool-Tip will be displayed during
the defined time in the status line of
the screen and explains the function
of the FB.
Call Language selection menu [5.4].
Load different languages for tool tips, menu and units from the directory Languages
