NETGEAR GS324T User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual116
14. In the Frame Size (1500 to 9198) field, specify the maximum Ethernet frame size that each
interface can support.
The frame size includes the Ethernet header, CRC, and payload. The range is 1500 to
9198. The default maximum frame size is 1500.
15. From the Flow Control menu, select the configuration for IEEE 802.3 flow control.
•
Disable. If the port buffers become full, the switch does not send pause frames, and
data loss could occur
. This is the default setting.
• Symmetric. If the port buffers become full, the switch sends pause frames to stop
traf
fic.
Flow control helps to prevent data loss when the port cannot keep up with the number
of frames being switched. When you enable flow control, the switch can send a pause
frame to stop traffic on the port if the amount of memory used by the packets on the
port exceeds a preconfigured threshold and responds to pause requests from partner
devices. The paused port does not forward packets for the time that is specified in the
pause frame. When the pause frame time elapses, or the utilization returns to a
specified low threshold, the switch enables the port to again transmit frames. The
switch also honors incoming pause frames by temporarily halting transmission.
• Asymmetric. If the port buf
fers become full, the switch does not send pause frames,
and data loss could occur
. However, the switch does honor incoming pause frames by
temporarily halting transmission.
Note: For LAG interfaces, flow control mode is displayed as a blank field
because flow control is not applicable.
16. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable data that is displayed.
Table 27. Port Configuration information
Field Description
Port Type For normal ports this field is blank. Otherwise, the options are as follows:
• Mirrored.
The port is a mirrored port on which all the traf
fic is copied to
the probe port.
• Probe. Use the port to monitor a mirrored port.
• Trunk Member.
The port is a member of a link aggregation trunk. Look
at the LAG pages for more information.
Physical Status The port speed and duplex mode.
Link Status Indicates whether the link is up or down.
MAC Address The physical address of the specified interface.

NETGEAR GS324T Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
ARP inspection	Yes
Master (outer) case width	270 mm
Master (outer) case height	271 mm
Master (outer) case length	481 mm
Master (outer) case weight	8850 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	3 pc(s)
Package type	Box
Package depth	465 mm
Package width	229 mm
Package height	79 mm
Package weight	2710 g
Cables included	AC
Stackable	-
Product color	Black
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	13.5 W
Operating temperature (T-T)	0 - 40 °C
MAC address table	16000 entries
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Private VLAN, Voice VLAN, Port-based VLAN
DHCP features	DHCP client

Weight and Dimensions

Depth	169 mm
Width	328 mm
Height	43 mm
Weight	1620 g
