S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Manage Device Security User Manual226
Configure the Dot1x Authentication List
The Dot1x authentication list defines the IEEE 802.1X authentication method used for the
default list. The default list is dot1xList.
To configure the dot1x authentication list:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Security > Management Security >
Authentication List > Dot1x
Authentication
List.
The Dot1x Authentication List page displays.
6. Select the check box next to dot1xList.
7. From the menu in the 1 column, select the method that must be used first in the selected
authentication login list.
The options are as follows:
• Local.
The user’s locally stored ID and password are used for authentication
•
Radius. The user
’s ID and password are authenticated using the RADIUS server
instead of locally.
• None. The user is not authenticated.
8. Click the Apply
button.
Your settings are saved.
