Configuring Switching
168
S3300 Smart Managed Pro Switch
STP Statistics
Use the Spanning Tree Statistics screen to view information about the number and type of
bridge protocol data units (BPDUs) transmitted and received on each port.
To display the Spanning Tree Statistics screen, select Sw
itching > STP > Advanced > STP
Statistics.
The following table describes the information a
vailable on the STP Statistics screen.
Table 57. STP statistics
Field Description
Interface The physical or port channel interface to view its statistics.
STP BPDUs Received Number of STP BPDUs received at the selected port.
STP BPDUs Transmitted Number of STP BPDUs transmitted from the selected port.
RSTP BPDUs Received Number of RSTP BPDUs received at the selected port.
RSTP BPDUs Transmitted Number of RSTP BPDUs transmitted from the selected port.
MSTP BPDUs Received Number of MSTP BPDUs received at the selected port.
MSTP BPDUs Transmitted Number of MSTP BPDUs transmitted from the selected port.
