NETGEAR S3300 User Manual

Configuring Switching
190
S3300 Smart Managed Pro Switch
Dynamic Address Configuration
Use the Dynamic Addresses screen to set the amount of time to keep a learned MAC
address entry in the forwarding database. The forwarding database contains static entries,
which are never aged out, and dynamically learned entries, which are removed if they are not
updated within a given time.
 To configure the dynamic address aging time-out value:
1. Select Switching > Address Table > Advanced > Dynamic Addresses.
2. In the Address Aging Timeout field, specify the number of seconds the forwarding database
should wait before deleting a learned entry that has not been updated.
Note: IEEE 802.1D recommends a default of 300 seconds, which is the
factory default value.
3. Click the Apply button.
Interface The port where this address was learned: that is, this field displays the port
through which the MAC address can be reached.
Status The status of this entry. The possible values are:
• Static. The entry was added when a static MAC filter was defined.
• Learned. The entry was learned by observing the source MAC addresses of
incoming traffic, and is currently in use.
• Management. The system MAC address, which is identified with interface c1.
Table 68. Address Table (continued)
Field Description

NETGEAR S3300 Specifications

General

Model	NETGEAR S3300
Category	Switch
VLAN Support	Yes
Quality of Service (QoS)	Yes
MAC Address Table Size	16K
Uplink Ports	4 x 10G SFP+
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 2+/Layer 3 Lite
Management	Web-based GUI, SNMP
Dimensions	440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame Support	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	90% maximum relative humidity, noncondensing
Power Supply	Internal power supply
Power Consumption	Varies by model
Ports	24 or 48 x 10/100/1000BASE-T
Weight	3.60 kg (7.94 lb)
