Page #170 background imageLoading...
Page #170 background image
Configuring Switching
170
S3300 Smart Managed Pro Switch
MFDB Statistics
This screen displays the MFDB statistics for the system.
To view the MFDB statistics:
Select Switchin
g> Multicast > MFDB > MFDB Statistics.
The MFDB Statistics screen displays the information shown in the following table.
Table 59. MFDB statistics
Field Description
Max MFDB Table Entries The maximum number of entries that the Multicast Forwarding Database table
can hold.
Most MFDB Entries Since
Last Reset
The largest number of entries that have be
en present in the Multicast
Forwarding Database table since last reset. This value is also known as the
MFDB high-water mark.
Current Entries The current number of entries in the Multicast
Forwarding Database table.
Description The text description of this multicast t
able entry. Possible values are
Management Configured, Network Configured and Network Assisted.
Interface The list of interfaces that are designated for forwa
rding (Fwd:) and filtering (Flt:)
for the selected address.
Forwarding Interfaces The resultant forwarding list is derived from combining all the forwarding
interfaces and removing the interfaces that are listed as the static filtering
interfaces.
Table 58. MFDB table information (continued)
Field Description
