360
B
B. Hardware Specifications and
Default Values
Switch Specifications
The switch conforms to the TCP/IP, UDP, HTTP, ICMP, TFTP, DHCP, IEEE 802.1D, IEEE
802.1p, and IEEE 802.1Q standards.
Table 108. S3300 Switch Specifications and Performance
Feature Value
S3300-28X 24 10/100/1000Mbps
2 10G/1G SFP+ ports
2 10G/1G/100M RJ45 ports
S3300-28X-PoE+ 24 POE+ 10/100/1000Mbps
2 10G/1G SFP+ ports
2 10G/1G/100M RJ45 ports
S3300-52X 48 10/100/1000Mbps
2 10G/1G SFP+ ports
2 10G/1G/100M RJ45 ports
S3300-52X-PoE+ 48 PoE+ 10/100/1000Mbps
2 10G/1G SFP+ ports
2 10G/1G/100M RJ45 ports
Flash memory size 64 MB Flash SPI
SRAM size and type 256 MB DDR3 SDRAM
Switching capacity Non-Blocking Full WireSpeed on all packet sizes
Forwarding method Store and Forward
Packet forwarding rate 10M:14,880 pps
100M:148,810 pps
1G:1,488,000 pps
10G:14,880,000 pps
MAC addresses 16K

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR S3300 and is the answer not in the manual?

NETGEAR S3300 Specifications

General IconGeneral
ModelNETGEAR S3300
CategorySwitch
VLAN SupportYes
Quality of Service (QoS)Yes
MAC Address Table Size16K
Uplink Ports4 x 10G SFP+
Switching Capacity128 Gbps
Forwarding Rate95.2 Mpps
LayerLayer 2+/Layer 3 Lite
ManagementWeb-based GUI, SNMP
Dimensions440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame SupportYes
Operating Temperature0°C to 50°C (32°F to 122°F)
Storage Temperature-20°C to 70°C (-4°F to 158°F)
Humidity90% maximum relative humidity, noncondensing
Power SupplyInternal power supply
Power ConsumptionVaries by model
Ports24 or 48 x 10/100/1000BASE-T
Weight3.60 kg (7.94 lb)
