NETGEAR S3300 User Manual

209
4
4. Configuring Routing
The switch supports IP routing. Use the menus under the Routing tab to manage routing on
the system.
When a packet enters the switch, the destination MAC address is checked to see if it
matches any of the configured routing interfaces. If it does, then the switch searches the host
table for a matching destination IP address. If an entry is found, then the packet is routed to
the host. If there is no matching entry, then the switch performs a longest prefix match on the
destination IP address. If an entry is found, then the packet is routed to the next hop. If there
is no match, then the packet is routed to the next hop specified in the default route. If there is
no default route configured, then the packet is passed to the software to be handled
appropriately.
The routing table can have entries added statically by the administrator. The host table can
have entries added either statically by the administrator or dynamically via ARP.
This chapter contains the following sections.
• Configure IP Settings on page 210
• Configure VLAN Routing on page 214
• Configure Router Discovery on page 216
• Configure and View Routes on page 217
• Configure ARP on page 219

NETGEAR S3300 Specifications

General

Model	NETGEAR S3300
Category	Switch
VLAN Support	Yes
Quality of Service (QoS)	Yes
MAC Address Table Size	16K
Uplink Ports	4 x 10G SFP+
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 2+/Layer 3 Lite
Management	Web-based GUI, SNMP
Dimensions	440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame Support	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	90% maximum relative humidity, noncondensing
Power Supply	Internal power supply
Power Consumption	Varies by model
Ports	24 or 48 x 10/100/1000BASE-T
Weight	3.60 kg (7.94 lb)
