Configuring Switching
169
S3300 Smart Managed Pro Switch
Multicast
Multicast IP traffic is traffic that is destined to a host group. Host groups for IPv4 multicast are
identified by class D addresses, which range from 224.0.0.0 to 239.255.255.255. Host
groups for IPv6 multicast are identified by the prefix ff00::/8.
From the Multicast link, you can access the following screens:
• MFDB Table
• MFDB Statistics
• Auto-Video
• IGMP Snooping
• IGMP Snooping Querier
• MLD Snooping
MFDB Table
The Multicast Forwarding Database (MFDB) holds the port membership information for all
active multicast address entries. The key for an entry consists of a VLAN ID and MAC
address pair. Entries can contain data for more than one protocol.
To search the MFDB table:
1. Select Switching> Multicast > MFDB > MFDB Table.
2. Next to Search By MAC Address, specify the MAC Address whose MFDB table entry you
want to view.
Enter six two-digit hexadecimal numbers separated by colons, for example
00:01:23:43:45:67.
3. Click the Go button.
If the address exists, that entry will be displayed. An exact match is required.
The MFDB Table screen displays the information shown in the following table.
Table 58. MFDB table information
Field Description
MAC Address The multicast MAC address for which you requested data.
VLAN ID The VLAN ID to which the multicast MAC address is related.
Component This is the component that is responsible for this entry in the Multicast
Forwarding Database. Possible values are IGMP Snooping, Static Filtering and
MLD Snooping.
Type This displays the type of the entry. Static entries are those that are configured by
the end user. Dynamic entries are added to the table as a result of a learning
process or protocol.
