Configure System Information
42
S3300 Smart Managed Pro Switch
Power Supplies
This screen shows the power supplies status.
Figure 23. System Information - Power Supplies Status
The following table describes the status information displayed in the Power Supplies section
of the System Information screen.
Table 7. System Information - Power Supplies Status Fields
Field Description
Unit The unit number in the stack.
Power Supply The power supply index used for the given stack member.
Description The description of the power supply.
Type Indicates whether the power supply is fixed or removable.
State Specifies whether the power modules
is operational or stopped.
Versions
This screen displays the software version of each device.
Figure 24. System Information - Versions Information
Duty Level The duty level of the fan.
State Specifies whether the fan is running or stopped.
Table 6. System Information - Fans Status Fields (continued)
Field Description
