Diffserv Configuration
Use the DiffServ Configuration screen to display DiffServ general status group information,
which includes the current administrative mode setting as well as the current and maximum
number of rows in each of the main DiffServ private MIB tables.
To configure the global DiffServ mode:
1. Select QoS > Di
ffServ > Advanced > DiffServ Configuration.
2. Next to Dif
fServ Admin Mode, select Enable.
If you disable DiffServ after it has been configured an
d enabled, the DiffServ configuration
is retained and can be changed, but it is not active.
3. Click the Appl
y button to send the updated configuration to the switch. Configuration
changes take effect immediately.
4. Click the Cancel
button to cancel the configuration on the screen, and reset the data on the
screen to the latest value of the switch.
The following table describes the information displayed in
the Status table on the DiffServ
Configuration screen:
Table 84. DiffServ MIB table information
Field Description
Class Table The current and maximum number of rows of the class table. The max size is 32.
Class Rule Table The current and maximum number of rows of the class rule table. The max size is 192.
Policy Table The current and maximum number of rows of the policy table. The max size is 32.
Policy Instance Table The current and maximum number of rows of the
policy instance table. The max size is
320.
Policy Attributes Table The current and maximum number of rows of the policy attributes table. The max size is
3
20.
Service Table The current and maximum number of rows of the service table. The max size is 338.
