NETGEAR S3300 User Manual

Managing Device Security
256
S3300 Smart Managed Pro Switch
Access Control
Access control allows you to configure a profile and set access rules.
Access Profile Configuration
Use the Access Profile Configuration screen to set up a security access profile.
 To configure an access profile:
1. Select Security > Access > Acces
s Control > Access Profile Configuration.
2. In
the Access Profile Name field, specify the name of the access profile to be added.
3. Select one of the fo
llowing options:
• Activate
Profile. Activate an access profile.
• Deactiva
te Profile. Deactivate an access profile.
• Remove
Profile. Remove an access profile. The access profile should be
deactivated before removing the access profile.
4. Click the Appl
y button.
The following table describes the access pro
file status information and the profile summary
information the screen displays.
Table 88. Access Profile Configuration
Field Description
Packets Filtered The number of packets filtered.
Profile Summary
Rule Type The action to be performed when the rules selected are matched.
Service Type The policy is restricted by the management chose
n from the list. Possible methods
include HTTP, Secure HTTP (SSL), and SNMP.
Source IP Address The Source IP Address of the client orig
inating the management traffic.
Mask The Source IP Address Mask of the client originating the management traffic.
Priority The rule priority value. The rules are
validated against the incoming management
request in the ascending order of their priorities. If a rule matches, action is
performed and subsequent rules below are ignored. For example, if a Source IP
10.10.10.10 is configured with priority 1 to permit, and Source IP 10.10.10.10 is
configured with priority 2 to Deny, then access is permitted if the profile is active,
and the second rule is ignored.
Access Rule Configuration
Use the Access Rule Configuration screen to add security access rules.
 To configure access rules:
1. Select Security > Acces
s > Access Control > Access Rule Configuration.

NETGEAR S3300 Specifications

General

Model	NETGEAR S3300
Category	Switch
VLAN Support	Yes
Quality of Service (QoS)	Yes
MAC Address Table Size	16K
Uplink Ports	4 x 10G SFP+
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 2+/Layer 3 Lite
Management	Web-based GUI, SNMP
Dimensions	440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame Support	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	90% maximum relative humidity, noncondensing
Power Supply	Internal power supply
Power Consumption	Varies by model
Ports	24 or 48 x 10/100/1000BASE-T
Weight	3.60 kg (7.94 lb)
