NETGEAR S3300 User Manual

Configure System Information
90
S3300 Smart Managed Pro Switch
PoE
Use this screen to configure a few system-level PoE parameters per unit. In other words, the
parameters are specific to the whole unit, not specific to any port(s).
1. Select System
> PoE > Basic > PoE Configuration.
Figure 51. PoE Basic Configuration
2. In the Unit Selection field, select a current PoE unit. You can change the PoE Unit by
selecting another unit ID listed in this field.
3. Configu
re the System Usage Threshold. Set a threshold level at which a trap is sent if
consumed power is greater than threshold power. Possible values are 1% to 99%. The
factory default is 95%.
4. Configu
re Power Management Mode. Describes or controls the power management
algorithm used by the PSE to deliver power to the requesting PDs. Possible values are:
• Dynamic. Power co
nsumption of each port is measured and calculated in real-time.
The default mode is Dynamic.
• St
atic. Power allocated for each port depends on the type of power threshold
configured on the port.
5. Configu
re Traps. Enable or Disable the activation of PoE traps by selecting the
corresponding check box. The factory default is Enable.
6. Click the Appl
y button to send the updated configuration to the switch. Configuration
changes take effect immediately.
7. Click the Can
cel button to cancel the configuration on the screen. The data on the screen is
reset to the latest value of the switch.
8. Click Up
date to update the page with the latest information on the switch.
The following table describes the non-configurable PoE Conf
iguration data that is displayed.
Table 31. PoE Configuration Non-configurable Data
Field Description
Firmware Version Version of the PoE controller’s FW image.
Power Status Indicates the power status.
Total Power (Main AC) Watt Maximum amount of power that is available
to the system from the
main AC source to deliver to all ports.
Total Power (RPS) Watt Maximum amount of power that is available to the system from an
external RPS supply to deliver to all ports.

NETGEAR S3300 Specifications

General

Model	NETGEAR S3300
Category	Switch
VLAN Support	Yes
Quality of Service (QoS)	Yes
MAC Address Table Size	16K
Uplink Ports	4 x 10G SFP+
Switching Capacity	128 Gbps
Forwarding Rate	95.2 Mpps
Layer	Layer 2+/Layer 3 Lite
Management	Web-based GUI, SNMP
Dimensions	440 x 257 x 43 mm (17.32 x 10.12 x 1.69 in)
Jumbo Frame Support	Yes
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Humidity	90% maximum relative humidity, noncondensing
Power Supply	Internal power supply
Power Consumption	Varies by model
Ports	24 or 48 x 10/100/1000BASE-T
Weight	3.60 kg (7.94 lb)
