Configure System Information
75
S3300 Smart Managed Pro Switch
Figure 45. Green Ethernet LPI History
2. In the Sampling Interval field, specify the frequency, in seconds, at which EEE LPI history.
3. In the Max
Samples to keep field, specify the maximum number of LPI samples to keep in
the history buffer.
4. Click the Ap
ply button.
To view per-interface LPI history information, select
the interface with the information to view
from the Interface list. The screen refreshes and displays the LPI history for the selected
interface.
The following table describes the status fields on the screen.
Table 22. LPI history information
Field Description
Percentage LPI time The percentage of time the switch spent in LPI mode.
Sample No. The current sample number. When the number increases to the
maximum, it rolls over and begins at 1.
Time Since The Sample Was
Recorde
d
The amount of time that has passed since the last LPI history
sample was recorded. Each time the screen is refreshed it shows
a different time as it reflects the difference in current time and time
at which the sample was recorded.
Percentage Time spent in LPI
mo
de since last sample
The percentage of time spent in LPI mode since the last sample
was recorded.
Percentage Time spent in LPI
mo
de since last reset
The percentage of time spent in LPI mode since the switch was
reset.
