104 Chapter 4 Use the PLC applications to control your workflow
Create destinations
3. Enter a name for the destination in the 'Name' text box.
This name will appear on the scanner panel.
4. From the 'Type' drop-down list box, select 'On the controller'.
5. Enter a path of the target folder in the 'Path' text box.
You can also click the 'Browse' button to select the path.
6. Click 'OK' to accept the destination properties.
Create a network destination with SMB
1. Create a shared folder on a workstation. For example c:\Scan.
2. From the 'File' menu on the Océ Scan Manager, select 'New'.
You can also click the 'New' button on the toolbar.
The 'Destination properties' dialog box opens.
3. From the 'Type' drop-down list box, select 'SMB'.
4. Enter the system name of the workstation where you created the shared folder in the
'System' text box.
Note: Find the system name of the workstation on the control panel of the
workstation (Control panel - Network - Identification - System name)
5. Enter a path of the target folder in the 'Path' text box.
The path name is the name of the shared folder on your workstation. For Windows
NT
®
, Windows
®
2000 and XP, use the DOS name of the shared folder. For Windows
95/98
®
use the folder name. This is case sensitive.
You can also select a shared folder from the drop-down list.
6. If you defined a user name and a password for the shared folder on the workstation,
then enter the user name and the password in the required fields.
Note: Make sure the user has write-access privileges on the destination.
7. Define the required file naming properties.
8. Click 'OK'.
Océ Scan Manager connects to the new SMB destination. Océ Scan Manager then
shows the contents of the new SMB destination.
