26 Chapter 2 Get to know the Océ TCS500 color printing system hardware
The scanner operator panel
The keys and their functions
[7]
[7] The keys and their functions (1 – 2)
Number Component Function
1 Green and red light Indicate the status of the scanner.
■ A green light indicates that the scanner is
ready.
■ A blinking green light indicates that the
scanner is busy.
■ A red light indicates that an error occurred.
■ A blinking red light indicates that the
scanner is busy and an error occurred.
2 Screen Show the system information in text and
icons.
3 and 12 Upper softkeys The upper-left softkey can have one of the
following functions.
■ Select the job, 'Copy' or 'Scan-to-file'.
■ Return to the home screen with the 'Home'
function.
■ Cancel a set with 'Cancel set' in case of a
set copy.
The upper-right softkey can have one of the
following functions.
■ Cancel a setting with the 'Cancel' function.
■ Create and close a set with the 'Create set'
and 'Close set' function.
4 Scroll-wheel key
■ Open a template or a setting
■ Close a setting
■ Define a toggle setting.
5 Scroll wheel
■ Scroll to a setting or template
■ Define the value of a setting.
6 and 10 Lower softkeys The lower-left softkey can have one of the
following functions.
■ Select another language.
■ Reset the settings of the templates with the
'Defaults' function.
The lower-right softkey can have one of the
following functions.
■ Close a setting with the 'Close' function.
■ Open the system settings with the 'System'
function.
