Oce TCS500 - Page 43

43
The optional copy receiving rack
[15]
How to adjust for standard print jobs
Attention: The copy receiving rack can collect a maximum of 15 prints in this
position. When you try to collect more prints, the prints can get damaged.
1. Place the rack with side I against the back of the printer.
2. Secure the rack with the breaks of the wheels.
3. Place the trailing edge stoppers at the end of the tray.
4. Adjust the rack with the guides into the position marked with the following figure.
[29]
[29] Rack adjustment for standard print jobs
Use the handles on the left and right guide to lower the tray.
Take the end of the tray to lift the tray.
Note: The position of the leading edge stopper is not important in this situation.
How to adjust for productive print jobs with same media sizes
Attention: The copy receiving rack can collect a maximum of 100 prints in this
position.
1. Place the rack with side II against the back of the printer.
2. Secure the rack with the breaks of the wheels.
3. Place the trailing edge stoppers at the end of the first sheet for a straight stack.
4. Adjust the rack with the guides into the position marked with the following figure.
[15] The components and functions of the copy receiving rack
Nr. Component Function
1 Adjust guides Adjust the rack
2 Leading edge stopper Stop the print at the leading edge
3 Trailing edge stopper Stop the print at the trailing edge
4 Left and right handle Lower the rack
5 End of the rack Lift the rack
