The optional copy receiving rack
[30]
[30] Rack adjustment for productive print jobs with same media sizes
Use the handles on the left and right guide to lower the tray.
Take the end of the tray to lift the tray.
5. Adjust the leading edge stopper into the position that is equal to the size of the print.
The marks on the leading edge stopper show the cut length in portrait direction.
Press the handle on the leading edge stopper to adjust the leading edge stopper.
Note: You can collect all types of media in this position except Photo-gloss and
Film.
How to adjust for productive print jobs with different media sizes
Attention: The copy receiving rack can collect a maximum of 100 prints in this
position.
1. Place the rack with side II against the back of the printer.
2. Secure the rack with the breaks of the wheels.
3. Place the trailing edge stoppers at the tray.
4. Adjust the rack with the guides into 1 of the 4 positions marked with the following
figure to find the balance for the longest print.
[31]
[31] Rack adjustment for productive print jobs with different media sizes
Use the handles on the left and right guide to lower the tray.
Take the end of the tray to lift the tray.
5. Adjust the leading edge stopper into the position that is equal to the size of the
shortest print.
The marks on the leading edge stopper show the cut length in portrait direction.
Press the handle on the leading edge stopper to adjust the leading edge stopper.
